Station details:
================

Code: ELBA
Latitude:  41.14690
Longitude:   28.43070
Elevation:   331.0
Depth:
Name: Catalca
Region: Turkey
Status:


Arrival picks statistics
Travel Time Analysis
On the top graph every dot represents the median residual for one month of data. The green line is the overall median; the orange line shows the standard deviation (smad) based on the median absolute deviation (mad), whilst the red line shows twice the standard deviation (2 * smad).
The bottom graph shows the number of residuals for each month. The red columns show the number of residuals whose median (for that month) is outside two standard deviations from the overall median (2 * smad).
Red dots indicate a possible clock error.


Station comments:
=================

CTT belongs to ISK network.ELBA station is 7 meters far from CTT and
ELBA belongs to DAD network.

Data at the ISC for 20 years between 2005 and 2024.
